CHEV 350 FLAT TOP PISTONS 4.030 BORE 5.70 RODS -5CC

Description

These ruggedly durable pistons are made with exclusive high strength FM425 alloy, and enhanced with 16.5% silicon for excellent tensile strength and scuff resistance. This advanced metallurgy permits tighter bore clearances, which help minimise noise on cold engine start-up. These pistons are the ideal choice for street performance applications and late-model replacement.
More Sealed Power hypereutectics benefits:
Higher strength than cast or forged at operating temperature

Finely dispersed silicon particles provide a highly resistant wear surface and reduces scuffing
Lower material growth allows pistons to be fit tighter, improving cylinder sealing for less blow-by and more power
High silicon content allows elimination of groove inserts in certain applications
Designed to retain standard ring gaps in the top groove
Piston Specifications :
CID: 355
Bore: 4.030

Stroke: 3.480
Rod Length: 5.700
Compression Height: 1.548
Compression Ratio with 58cc chamber volume: 10.79
Compression Ratio with 64cc chamber volume: 10.06
Compression Ratio with 76cc chamber volume: 8.88
Dome Volume: -6.9cc
Pin Type: Press or Floated

Ring Size: 5/64″ – 5/64″ – 3/16″

Recommended Ring Set: Cast – SPE251X 030, Moly – SPE251K 030
