Weight 5.2 kg
Brand

Diamond

FORD XR6 TURBO 3.632″ BOR -4cc3.910 ST 6.058″ ROD 1.215″ C/H

SKU: D30206-6
Out of stock. New stock arriving weekly. Call 9353 1155 to order.

$1,944.56

Add to Wishlist
Add to Wishlist
Out of stock. New stock arriving weekly. Call 9353 1155 to order.

Did you like this product? Add to favorites now and follow the product.

Add to Wishlist
Add to Wishlist

Description

Piston
Specifications:

  • Block:
    Ford Barra 4.0L
    Turbo
  • Bore:
    3.632
  • Stroke:
    3.910
  • Rod:
    6.058
  • Comp Heigh:
    1.215″
  • Weight:
    N/A
  • Pin: .866 x
    2.500″
  • CC’s: Dish Top
    -4.0
  • Comp Ratio With
    70cc Head: 9.5
  • Ring
    Set:
    09533632


Piston
Features:

  • 3D milling on piston crowns
    for ready to install
    finish
  • Offset pins for
    quiet operation
  • Moly
    skirt coating for friction
    loss and skirt wear
    protection
  • Side gas
    ports for better ring
    seal
  • Ratios figured
    for 94mm x .040 head gasket @
    9.228 Deck Height
  • Top
    ring down dimension:
    .280″
  • Premium 8620
    .180W wrist pins chamfered for
    roundwire locks
    included
  • Premium 1.0mm
    x 1.2mm x 2.8mm ring package
    included
  • Oversized
    valve pockets – for larger
    than stock valve
    sizes
  • Valve pocket
    depth: 0.122″ intake and
    0.000″ exhaust
  • 2618
    material for High HP/Boost
    applications

Additional information

Weight 5.2 kg
Brand

Diamond
