Description
As the leader in forged racing pistons, JE Pistons hasapplied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons’ performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.
Forged in the USA using 2618 aluminium, yielding high tensile strengthneeded for high-demand performance applications
Designed specifically for each engine and use application to provideoptimized performance durability
ProprietaryForged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
Includes high-quality wrist pins, locks, and JE Pro Seal premiumpiston rings
Made 100%in the USA
Specifications:
Piston Series: JE Pistons
Cylinder Head: 2.0L ZETEC
Bore Diameter:85.00mm
Piston Head Type:Dome
Compression Height: 1.171″
Piston Volume: 5cc
Piston Material: 2618
Piston Quantity: 4
Forging Type:FSR
Piston Average Weight: 319g
Ring Set Included: Yes
Top Compression Ring Thickness: 0.0400″
Second Compression Ring Thickness: 0.0480″
Oil Ring Thickness: 0.111″
Wrist Pin Outer Diameter: .787″
Wrist Pin Length: 2.250″
Wrist Pin Wall Thickness: 0.180″
Additional information
| Weight | 2.4040 kg |
|---|---|
| Dimensions | 22.90 × 12.70 × 22.90 cm |
| Category list | |
| Brand | Je Pistons |
