LS3 4.065″ PISTONS -5cc FLAT 3.622″ ST 6.098″ ROD 1.340″ CH

Description

Piston Package
Includes:

Rings:

• Lightweig
  ht, low friction metric ring
  package included
• 1.2mm
  top ring, 1.5mm Napier 2nd
  ring, 3.0mm standard tension
  oil ring
• Napier 2nd
  ring for improved oil
  control
• Standard fit
  rings, minimal filing
  required

Pins &
Locks:

• High quality 2.250″ pin
  further reduces reciprocating
  weight
• Carbon steel
  wire locks
  included

Specifications:

• Part #:
  SRP329379
• CID:
  376
• Bore:
  4.065
• Stroke:
  3.622
• Rod Length:
  6.098
• Compression
  Height:
  1.340
• Compression
  Ratio with 64cc chamber
  volume:
  10.8
• Compression Ratio
  with 66cc chamber volume:
  10.6
• Compression Ratio
  with 72cc chamber volume:
  9.9
• Dome Volume:
  -5.0cc
• Gram Weight:
  438
• Footnote:
• Oversize: STD
  LS3
• Replacement Ring
  Set (Included)
  JG31F8-4070-5

SRP
Pistons is proud to announce a
new addition to our very
popular product line,”SRP
Professional.” SRP
Professional pistons include
features used in professional
racing such as lightweight
forged side relief (FSR)
forgings, high quality wrist
pins, and precision CNC
machined ring grooves and
skirts. In addition, every
package includes JE Pro Seal
Premium Piston Rings. The
included ring set features a
1.2 premium steel top ring,
1.5mm Napier (hooked face)
second ring and 3.0mm standard
tension oil ring. Every piston
is designed and manufactured
in the USA at the advanced
JE/SRP Pistons manufacturing
center. Nick Diblasi, JE/SRP
Pistons Product Manager feels,
“This new line of SRP Pistons
will change everything the
industry knows about
affordable forged pistons. The
features you would normally
find in a high quality set of
JE Pistons can be found at the
affordable price of SRP
Pistons. There is nothing
comparable on the market.”
